6.5 Home network configuration
Connect the tablet and the Printed Circuit Board (PCB) to the home network. This option is preferred if
the home network provides sufficient coverage around the pool.
Connect tablet to Printed Circuit Board (PCB):
On the tablet, open the screen with WiFi connections, and connect to the network:
EVAcontroller AP ######
A screen with the EVA logo will automatically appear. Click on Continue under the logo.
Connect Printed Circuit Board (PCB) to home network:
The following setup screen opens automatically:
1. Select Station Mode next to Network Mode.
2. Choose your Home network next to Network SSID.
3. Enter your Password next to Password.
4. Check if evacontroller is filled in next to Hostname.
5. The other settings usually do not need to be changed. Click the save icon at the top right.
1
2
Connect the tablet to home network:
Open the screen with WiFi connections on the tablet and connect to the home network.
4
Disconnect the wifi connection on the Printed Circuit Board (PCB):
On the Printed Circuit Board (PCB), switch the ENA WIFI button to OFF (slide switch 2 back to the
left). The PCB is now connected to the home network.
WIFI
turn Off
3
