EVAPCO LSTB Series - AT;USS 6ʼ, 8ʼ & 8.5ʼ Wide Towers

25
Operation and Maintenance Instructions
AT/USS 6’, 8’ & 8.5’ WIDE TOWERS
FAN & FILL CASING SECTION
PAN & PLENUM SECTION
FAN CYLINDER
FAN SCREEN
BEARING SUPPORT
CONNECTION SIDE
FAN SREEN
SUPPORT
FAN
SWING OUT
MOTOR COVER
FILL
SPRAY BRANCH
ACCESS DOOR
FAN BELT
FAN MOTOR SHEAVE
TEFC FAN MOTOR
DRIFT
ELIMINATORS
PLENUM SECTION
MAKE-UP VALVE WITH
ADJUSTABLE FLOAT
WATER OUTLET
CONNECTION
COLD WATER BASIN
FRAMED AIR
INLET LOUVER
AIR INLET
LOUVER MEDIA
SUCTION HOOD
& STRAINER
MOTOR SIDE
