EVAPCO LSTB Series - UT 10ʼ, 12ʼ, & 14ʼ Wide Towers

31
Operation and Maintenance Instructions
UT 10’, 12’, & 14 Wide Towers
FAN & FILL CASING SECTION
FAN SCREEN
FAN CYLINDER
DRIFT ELIMINATORS
FILL
WATER DISTRIBUTION
SPRAY BRANCH
ACCESS DOOR
FAN BELT
ALUMINUM FAN SHEAVE
TEAO FAN MOTOR
SLIDING MOTOR BASE
FAN SCREEN SUPPORT
MECHANICAL
EQUIPMENT
SUPPORT
SUPER LOW SOUND FAN
CONNECTION SIDE
AIR INLET
LOUVER MEDIA
MAKE-UP VALVE WITH
ADJUSTABLE FLOAT
SUCTION HOOD
&STRAINER
COLD WATER BASIN
FRAMED AIR
INLET LOUVER
WATER OUTLET
CONNECTION
PLENUM SECTION
MOTOR SIDE
PAN & PLENUM SECTION
