Operation and Maintenance Instructions
AT/USS 10’, 12’, & 14’ Wide Towers
FAN & FILL CASING SECTION
PAN & PLENUM SECTION
CONNECTION SIDE
FAN CYLINDER
DRIFT
ELIMINATORS
FILL
ALUMINUM FAN SHEAVE
FAN BELT
WATER DISTRIBUTION
SPRAY BRANCH
ACCESS DOOR
TEFC FAN MOTOR
SLIDING MOTOR BASE
FAN SCREEN
FAN SCREEN SUPPORT
FAN
MECHANICAL
EQUIPMENT SUPPORT
PLENUM SECTION
MAKE-UP VALVE WITH
ADJUSTABLE FLOAT
WATER OUTLET
CONNECTION
FRAMED AIR
INLET LOUVER
COLD WATER BASIN
AIR INLET
LOUVER MEDIA
SUCTION HOOD
& STRAINER
MOTOR SIDE
