EVAPCO LSTB Series - UT 20ʼ & 24ʼ Wide Towers

33
Operation and Maintenance Instructions
UT 20’ & 24’ Wide Towers
FAN & FILL CASING SECTION
FAN SCREEN
FAN CYLINDER
DRIFT ELIMINATORS
FILL
WATER DISTRIBUTION
SPRAY BRANCH
WATER DISTRIBUTION
HEADER BOX
WATER INLET CONNECTION
ACCESS DOOR
ALUMINUM FAN SHEAVE
TEAO FAN MOTOR
SLIDING MOTOR BASE
FAN SCREEN SUPPORT
MECHANICAL
EQUIPMENT
SUPPORT
SUPER LOW SOUND FAN
PAN & PLENUM SECTION
AIR INLET
LOUVER MEDIA
MAKE-UP VALVE
WITH ADJUSTABLE
FLOAT
SUCTION HOOD
& STRAINER
COLD WATER
BASIN
FRAMED AIR
INLET LOUVER
WATER OUTLET
CONNECTION
PLENUM SECTION
LOUVER
ACCESS
DOOR
