EVAPCO LSTB Series - UT 12ʼ, 15ʼ & 17ʼ Wide End Connection Towers

32
Operation and Maintenance Instructions
UT 12’, 15’ & 17’ Wide End Connection Towers
FAN & FILL CASING SECTION
FAN SCREEN
FAN CYLINDER
DRIFT ELIMINATORS
FILL
WATER INLET CONNECTION
WATER DISTRIBUTION
HEADER BOX
SPRAY BRANCH
ACCESS DOOR
FAN BELT
FAN MOTOR SHEAVE
TEFC FAN MOTOR
SWING OUT
MOTOR COVER
FAN SCREEN SUPPORT
BEARING SUPPORT
SUPER LOW SOUND FAN
AIR INLET
LOUVER MEDIA
MAKE-UP VALVE WITH
ADJUSTABLE FLOAT
SUCTION HOOD
& STRAINER
COLD WATER BASIN
FRAMED AIR
INLET LOUVER
WATER
OUTLET
CONNECTION
PLENUM SECTION
MOTOR SIDE
PAN & PLENUM SECTION
