Operation and Maintenance Instructions
AT/USS 28’ Wide Towers
FAN & FILL CASING SECTION
PAN & PLENUM SECTION
ACCESS DOOR
TEAO FAN MOTOR
SLIDING MOTOR BASE
MECHANICAL
EQUIPMENT
SUPPORT
FAN SCREEN
FAN CYLINDER
D
RIFT ELIMINATORS
FILL
WATER INLET CONNECTION
WATER DISTRIBUTION SPRAY BRANCH
ALUMINUM FAN SHEAVE
FAN BELT
FAN SCREEN SUPPORT
FAN
PLENUM SECTION
MAKE-UP VALVE
WITH ADJUSTABLE FLOAT
WATER OUTLET
CONNECTION
SUCTION HOOD
& STRAINER
AIR INLET LOUVER MEDIA
COLD WATER BASIN
FRAMED AIR
INLET LOUVER
