LED COLOUR MEANING
RED
LED for the unit of measurement of the value shown on the upper display when the probe is
configured for pressure
RED
IB/RS485 LED
- BLINK if an INTRABUS/RS485 communication is underway
- OFF if no communication is underway
The table below shows the meaning of the LED signals of EVD CHIL.
LED COLORE SIGNIFICATO
ON GREEN
Power supply LED
- ON if the controller is powered
- OFF if the controller is not powered
RUN GREEN
“RUN” LED
- ON if the controller is switched on
- OFF if the controller is switched off
∆ RED
Alarm LED
- ON if an alarm is underway
- OFF if no alarm is underway
IB AMBER
INTRABUS LED
- BLINK if an INTRABUS communication is underway
- OFF if no communication is underway
RS485 AMBER
RS-485 LED
- BLINK if an RS-485 communication is underway
- OFF if no communication is underway
