EVCO S.p.A. EV3 CHIL & EVD CHIL | Installer manual ver. 1.2 | Code 1443DCHILE124
page 28 of 46
M CF35 2 0 4 - - - -
AO1 output configuration type
0= Disabled
1= Phase cutting [%]
2= 0-10V [%]
3= PWM [%]
4= Frequency [Hz]
The choice of CF35 value determines the unit of
measurement for adjusting the compressor (Hz or %)
M CF36 1 0 4 - - - -
AO2 output configuration type
0 = Disabled
1= Phase cutting [%]
2= 0-10V [%]
3= PWM [%]
4= Frequency [Hz]
The choice of CF36 value determines the unit of
measurement for adjusting the fan (Hz or %)
M CF47 0 0 4 - - - -
AO1 analogue output function configuration
0= Disabled
1= Not used
2= Not used
3= Not used
4= Modulating compressor (in this case, the second
compressor cannot be used)
M CF51 0 0 1 - - - -
RUN Logo
0= Off
1= On
MENU PARAM. DEFAULT MIN. MAX. U.M. ALARMS
M AL01 3 0 255 - - - -
Number of alarms in an hour for low pressure after which
the alarm switches from automatic to manual re-arm
M AL02 40 0 255 s Low pressure alarm bypass time
M AL05 40.0 -50.0 80.0 °C-Bar High pressure alarm set-point
M AL06 5.0 -12.7 12.7 °C-Bar High pressure alarm hysteresis
M AL07 2 0 255 - - - -
Number of flow alarms in an hour after which the alarm
switches from automatic to manual re-arm
M AL08 15 0 255 s Bypass time for flow alarm from pump activation
M AL09 3 0 255 s Flow alarm delay from activating flow switch input
