EVCO S.p.A. EV3 CHIL & EVD CHIL | Installer manual ver. 1.2 | Code 1443DCHILE124
page 29 of 46
M AL10 5 0 255 s
Flow alarm re-arm delay from deactivating flow switch
input
S AL12 3,0 -127 127 °C Antifreeze alarm set-point
S AL13 2.0 0.0 25.5 °C Antifreeze alarm hysteresis
M Al14 0 0 1 - - - -
Stop fan with antifreeze alarm
0= Disabled
1= Enabled
M Al17 105.0 0.0 255.0 °C High discharge temperature alarm set-point
M AL18 15.0 0.0 25.5 °C High discharge temperature alarm hysteresis
MENU PARAM. DEFAULT MIN. MAX. U.M. COMPRESSOR
M CP01 1 0 255 s*10 Compressor OFF minimum time
M CP02 36 0 255 s*10 Compressor successive switch-ons minimum time
M CP05 20 10 CP06 Hz - % Minimum modulating compressor value
M CP06 100 CP05 255 Hz - % Maximum modulating compressor value
M CP08 0.0 0.0 25,5 °C
Cut-off hysteresis for modulating compressor adjustment
(“CooL”)
For ON-OFF adjustment set to 0
M CP09 0 0 255 Hz - % Set-point for refreshing the modulating compressor oil
M CP10 0 0 255 min Delay for refreshing the modulating compressor oil
MENU PARAM. DEFAULT MIN. MAX. U.M. COMPRESSOR ADJUSTMENT
S rL01 5.0 0.0 25.5 °C Proportional compressor adjustment band
S rL04 0 0 255 s*10 Compressor adjustment integral time
MENU PARAM. DEFAULT MIN. MAX. U.M. VENTILATION
M Fn01 20 0 255 s/10
Fan start-up time, if CF36 is set to 1 (AO2 output
configuration type = phase cutting)
M Fn02 1 0 10 ms/2 Fan phase shift
M Fn03 0 0 1 - - - -
Fan mode
0= On-call (dependant on the compressor)
1= Independent
