EVCO S.p.A. EV3 CHIL & EVD CHIL | Installer manual ver. 1.2 | Code 1443DCHILE124
page 30 of 46
M Fn04 2.0 0.0 25.5 °C-Bar Fan adjustment delta cut-off
M Fn05 1.0 0.0 25.5 °C-Bar Fan cut-off hysteresis
M Fn06 20 0 255 s Fan cut-off bypass time
M Fn07 30 0 100 Hz - % Minimum fan speed
M Fn08 100 0 100 Hz - % Maximum silent-running fan speed
M Fn09 28.0 -50.0 80.0 °C-Bar Minimum fan speed set-point
M Fn10 4.0 0.0 25.5 °C-Bar Fan adjustment proportional band
M Fn11 100 0 100 Hz - % Maximum fan speed
M Fn12 35.0 -50.0 80.0 °C-Bar Maximum fan speed set-point
M Fn13 30 0 255 s Pre-ventilation time
MENU PARAM. DEFAULT MIN. MAX. U.M. PUMP
M PM01 20 0 255 s Compressor switch-on delay from pump switch-on
M PM02 10 0 255 s Pump switch-off delay from compressor switch-off
M PM03 1 0 1 - - - -
Pump ON mode at request
0= disabled (pump on constantly)
1= enabled
S PM04 4.0 -127 127 °C Antifreeze set-point for activating pump
S PM05 2.0 0.0 25.5 °C Antifreeze hysteresis for activating pump
MENU PARAM. DEFAULT MIN. MAX. U.M. PROBE OFFSET
S oF01 0.0 -12.7 12.7 °C Offset analogue input 1 (IN1)
S oF02 0.0 -12.7 12.7 °C Offset analogue input 2 (IN2)
S oF03 0.0 -12.7 12.7 °C Offset analogue input 3 (IN3)
S oF04 0.0 -12.7 12.7 °C Offset analogue input 4 (IN4)
