Label Default Min. Max. U.M. Description
11 = Heater thermal switch (NO)
12 = Thermostat request (NO)
13 = Dehumidifier request (NO)
14 = External air damper open limit switch (NO)
15 = External air damper closed limit switch (NO)
16 = Forced ventilation (NO)
17 = Filter pressure switch (NO)
100 = Room probe
101 = Supply probe
102 = External probe
103 = Discharge probe
104 = Water probe
105 = Compressor defrost probe
106 = Compressor discharge temperature probe
107 = Humidity probe
108 = CO
2
probe
109 = Remote control probe
110 = Differential pressure transducer
I02 101 -17 110 IN2 input function configuration; see parameter I01
I03 102 -17 106
IN3 input function configuration
-17 = Filter pressure switch (NC)
-16 = Forced ventilation (NC)
-15 = External air damper closed limit switch (NC)
-14 = External air damper open limit switch (NC)
-13 = Dehumidifier request (NC)
-12 = Thermostat request (NC)
-11 = Heater thermal switch (NC)
-10 = Coil water antifreeze (NC)
-9 = Season change (NC)
-8 = remote ON-OFF (NC)
-7 = Compressor thermal switch (NC)
-6 = Low pressure (NC)
-5 = High pressure (NC)
-4 = Return flow switch (NC)
-3 = Supply flow switch (NC)
-2 = Return fan flow switch (NC)
-1 = Supply fan flow switch (NC)
0 = Disabled
1 = Supply fan flow switch (NO)
2 = Return fan flow switch (NO)
3 = Supply flow switch (NO)
4 = Return flow switch (NO)
5 = High pressure (NO)
6 = Low pressure (NO)
7 = Compressor thermal switch (NO)
8 = remote ON-OFF (NO)
9 = Season change (NO)
10 = Coil water antifreeze (NO)
11 = Heater thermal switch (NO)
12 = Thermostat request (NO)
13 = Dehumidifier request (NO)
14 = External air damper open limit switch (NO)
15 = External air damper closed limit switch (NO)
