EVCO S.p.A. EV3 MVC & EVD MVC | Application manual ver. 1.0 | Code 144EV3MVI104
page 40 of 72
8 INPUT/OUTPUT CONFIGURATION
8.1 Inputs
All ten inputs can be used as digital inputs but only some (IN1, IN2, IN3, IN4, IN5, IN6 and IN7 on EV3 MVC; IN1, IN2, IN3, IN4, IN5,
IN9 and IN10 on EVD MVC) can be configured as analogue.
Inputs IN1 and IN2 can be configured using parameters I23, I24 (controller), I26 and I27 (expansion), as shown in the table below,
whereas the other analogue inputs are of the temperature type.
Type AI universal
Parameter value
I23 - I24 - I26 - I27
Description
0 NTC / Digital input
1 4-20 mA
2 0-10 V
Important: in EV3 MVC, if one of the inputs IN1/IN2 has been set to power, the other one must also be. If this does not happen the
reading of the input set to power will be affected by the offset.
The type of probe chosen affects the unit in which measurements are taken: probes measuring temperature are in °C or °F according
to the parameter C59 setting, while probes measuring power or voltage use the units Pa or % (%rh in EVJ LCD) according to the
conversion scales set by parameters I29-I32 that determine the values at both ends of the scale for sensors configured as humidity,
CO
2
, pressure or remote control probes.
AI/DI configuration
Parameter value
(absolute value)
I01 - I20
Description
0 Disabled
1 Supply fan thermal switch
2 Return fan thermal switch
3 Supply flow switch
4 Return flow switch
5 High pressure
6 Low pressure
7 Compressor thermal switch
8 Remote ON-OFF
9 Season change
10 Coil water antifreeze
11 Heater thermal switch
12 Thermostat request
13 Dehumidifier request
14 External air damper open limit switch
15 External air damper closed limit switch
16 Forced ventilation
17 Filter pressure switch
