EVCO S.p.A.
EV3 MVC & EVD MVC | Application manual ver. 1.0 | Code 144EV3MVI104
page 66 of 72
- Plug-in screw terminal block (RS-485 MODBUS port).
EVD MVC
EVD EXP
- Micro-Fit connector (analogue inputs, digital inputs, open collector output)
- Plug-in screw terminal blocks (power supply, electro-mechanical relays, INTRABUS
port and RS-485 MODBUS port).
EV3K11 Plug-in screw terminal block (power supply and INTRABUS port).
EVJ LCD Fixed screw terminal block (power supply and INTRABUS port).
The maximum length of the connection cables are as follows:
- Power supply: 10 m (32.8 ft)
- Analogue inputs: 10 m (32.8 ft)
- Power supply for transducer analogue inputs 4-20mA: 10 m (32.8 ft)
- Digital inputs: 10 m (32.8 ft)
- Analogue outputs 0-10 V: 10 m (32.8 ft)
- Phase cutting analogue outputs: 10 m (32.8 ft)
- PWM analogue outputs: 1 m (3.28 ft)
- Digital outputs: 10 m (32.8 ft)
- INTRABUS ports: 10 m (32.8 ft)
- RS-485 MODBUS ports: 1,000 m (3,280 ft); see also the MODBUS manual "specifications and
implementation guides" available on http://www.MODBUS.org/specs.php.
- USB port, 1 m (3.28 ft)
Use cables of an adequate section for the current running through them.
For EV3 MVC cabling we recommend using the CJAV39 connection kit (to be ordered separately). For
EVD MVC and EVD EXP cabling we recommend using the CJAV38 connection kit (to be ordered
separately).
Operating temperature
EV3 MVC from -10 to 55 °C (from 14 to 131 °F)
EVD MVC
EVD EXP
from -10 to 55 °C (from 14 to 131 °F)
EV3K11 from 0 to 55 °C (from 32 to 131 °F)
EVJ LCD from 0 to 40 °C (from 32 to 104 °F)
Storage temperature
EV3 MVC
from -20 to 70 °C (from -4 to 158 °F)
EVD MVC
EVD EXP
EV3K11
EVJ LCD
Operating humidity
EV3 MVC
Relative humidity without condensate from 10 to 90%
EVD MVC
EVD EXP
EV3K11
EVJ LCD Relative humidity without condensate from 5 to 95%
Pollution status of the
control device
EV3 MVC
2
EVD MVC
EVD EXP
EV3K11
EVJ LCD
Compliance:
EV3 MVC
- RoHS 2011/65/EC
- WEEE 2012/19/EU
EVD MVC
