EVCO S.p.A. EVDRIVE03 | User manual ver. 3.7 | Code 144EPDE374
Page 44 of 76
Par. Min. Mas. Unità Default Menu Probe settings: analog input AI2
Piu2 0 2 - - - - 0 Manufact.
analog input AI2 function
0 = not used
1 = suction temperature backup probe
2 = suction pressure backup probe
Pia2 1 30 - - - - 1 Installer
analog input AI2 probe type (used if Piu2
= 1 or 2)
1 = NTC probe
6 = Pt 1000 probe
10 = 4÷20 mA transducer (0÷10 Barg)
11 = 4÷20 mA transducer (0÷16 Barg)
12 = 4÷20 mA transducer (0÷30 Barg)
13 = 4÷20 mA transducer (0÷50 Barg)
20 = 0÷5 V ratiometric transducer (0÷7
Barg)
21 = 0÷5 V ratiometric transducer
(0÷25 Barg)
22 = 0÷5 V ratiometric transducer
(0÷60 Barg)
30 = scaling
AI2T 2 7 - - - - ??? User
AI1 type (used if Piu2 = 0)
2 = NTC
3 = 0-20 mA
4 = 4-20 mA
5 = 0-5 V
6 = reserved
7 = Pt 1000
Par. Min. Mas. Unità Default Menu
Probe settings: analog input AI2
scaling
P2Xty 0 2 - - - - 0 Manufact.
X type
0 = 0-20 mA
1 = 4-20 mA
2 = 0-5 V
P2XM P2Xm
0:20.00
1:20.00
2:5.00
- - - - 20.00 Manufact. X max value
P2Xm
0:0.00
1:4.00
2:0.00
P2XM - - - - 0.00 Manufact. X min value
P2Yty 0 1 - - - - 0 Manufact.
Y type
0 = barG
1 = barA
