EVCO S.p.A. EVDRIVE03 | User manual ver. 3.7 | Code 144EPDE374
Page 45 of 76
P2YM P2Ym 300.00 barG/barA 1.00 Manufact. Y max value
P2Ym
-
300.00
P2YM barG/barA 0.00 Manufact. Y min value
Par. Min. Mas. Unità Default Menu Probe settings: analog input AI3
Piu3 3 3 - - - - 3 Manufact.
analog input AI3 function
3 = suction temperature probe
Pia3 1 6 - - - - 1 Manufact.
analog input AI3 probe type
1 = NTC probe
6 = Pt 1000 probe
Par. Min. Mas. Unità Default Menu Probe settings: analog input AI4
Piu4 4 4 - - - - 4 Manufact.
analog input AI4 function
4 = suction pressure probe
Pia4 10 30 - - - - 10 Installer
analog input AI4 probe type
10 = 4÷20 mA transducer (0÷10 Barg)
11 = 4÷20 mA transducer (0÷16 Barg)
12 = 4÷20 mA transducer (0÷30 Barg)
13 = 4÷20 mA transducer (0÷50 Barg)
20 = 0÷5 V ratiometric transducer (0÷7
Barg)
21 = 0÷5 V ratiometric transducer
(0÷25 Barg)
22 = 0÷5 V ratiometric transducer
(0÷60 Barg)
30 = scaling
Par. Min. Mas. Unità Default Menu
Probe settings: analog input AI4
scaling
P4Xty 0 3 - - - - 0 Manufact.
X type
0 = 0-20 mA
1 = 4-20 mA
2 = 0-5 V
3 = 0-10 V
P4XM P4Xm
0:20.00
1:20.00
2:5.00
3:10.00
- - - - 20.00 Manufact. X max value
