EVCO S.p.A. EVDRIVE03 | User manual ver. 3.7 | Code 144EPDE374
Page 47 of 76
Mb1b 4 4 - - - - 4 Manufact.
MODBUS prog port baud rate
0 = 1,200
1 = 2,400
2 = 4,800
3 = 9,600
4 = 19,200
Mb1s 0 0 - - - - 0 Manufact.
MODBUS prog port stop bit
0 = 1 bit
1 = 2 bit
CANn 1 127 - - - - 11 Manufact. CAN node address
CANb 0 4 - - - - 1 Manufact.
CAN baud rate
0 = 10K
1 = 20K
2 = 50K
3 = 125K
4 = 500K
Par. Min. Mas. Unità Default Menu Command
Pr02 0 2 - - - - 0 User
functioning mode
0 = SH-ALGORITHM
1 = manual mode
2 = debug functionality
Pr03 0.00 100.00 % 0.00 User
manual setpoint position (only if Pr02 =
1)
ResR 0 1 - - - - 0 User resynchronization request
EnaV 0 1 - - - - 0 User
enable valve command (RS-485 or
external MODBUS)
0 = disable valve
1 = enable valve
Cmd 0 65535 - - - - 0 User
command (b0: 0 -> 1 reset parameter
alarm; Cmd: x -> 0zBx reset application;
Cmd: x -> 0x5x reset board)
Par. Min. Mas. Unità Default Menu Status
UdM - - - - - - - - - - - - - - - - User
internal unit of measure
b0: 0: pressure in bar
1: pressure in psi
b1: 0: temperature in °C/K
1: temperature in °F/R
b2: 0: conversion ok
1: conversion in progress or
halted
