10.3.2 Description
The following drawing shows the aspect of the interface EVIF20SUXI.
The following table shows the meaning of the parts of the kit.
Part Meaning
1 USB cable 2 m (6 ft) long
2 RS-485 cable 2.5 m (8 ft) long
3 RS-485 port on telephone connector
4 RS-485 port on screw terminal block
5 RS-485 / USB non optoisolated serial interface
6 USB port
