40
41
Lap/shoulder seat belt
combination that has a
buckle tongue that slides
freely along the belt
without locking into
place and is equipped with
an emergency locking
retractor (ELR).
Some ELR vehicle belts can
be switched so that they lock
when tightened.
Locking Clip
Use the locking clip with:
Remove locking clip from vehicle seat belt when
not used with a child restraint, or the vehicle seat
belt will not properly restrain an adult or child.
Serious injury could occur.
WARNING
To watch a video about installing a locking clip, go to
www.evenflo.com.
Push down
on the base using
your foot or
knee.
Remove the locking clip from the slot in your
convenience base.
Thread the seat belt through the base openings for
the vehicle belt path, and buckle the seat belt.
Pull the shoulder belt tightly to remove all slack
from the lap portion of the belt.
➚
Using the Locking Clip
1
TIP!
TIP!
13 mm (0.5 in.)
While holding the belts and
buckle tongue , thread
the locking clip onto the
seat belt, and slide it into
place.
Note: Locking clip must be
placed within 13 mm
(0.5 in.) of seat belt buckle.
3
Hold the lap/shoulder belts together just behind the
free sliding buckle tongue and unfasten the seat
belt.
2
4
Buckle the seat belt with
the locking clip in
place.
• If installing the convenience base with a vehicle seat
belt, return to page 22, Step 3.
• If installing the carrier (no convenience base) with a
vehicle seat belt, return to page 29, Step 4.
Consult your vehicle owner’s manual before
installing the locking clip.
