Evenheat Rampmaster RM3 - Rampmaster Display Conditions; Rampmaster Display Messages

Rampmaster Operating Manual
Heat Treat ver. RM3 – Feb 2017
Page 13 of 25
Use your Smart-phone to scan this QR code to watch Rampmaster how-to Programming Videos!
Rampmaster Display Conditions
The LED display of the Rampmaster displays different data depending upon what’s happening. Listed below are the possible display conditions.
Display Alternating Between STbY (Standby) and Temperature — Program is not running: oven chamber temperature is displayed.
Display Reading Temperature - Program is running and is ramping to temperature: oven chamber temperature is displayed.
Display Alternating Between Time Value and Temperature - Program is running and is holding at temperature: oven chamber temperature is displayed
along with the time value counting down remaining hold time.
Display Reading a Decreasing Time Value—Program is running with a delay start: the time value counting down is the remaining delay start time.
Dot Displayed Between the 10’s and 100’s Digits — Indicates the value being displayed is a time value.
Dot Displayed to the Right of the 1’s Digit — Indicates that a Celsius temperature is being displayed. If no dot is displayed the Rampmaster is displaying in
Fahrenheit.
Display Alternating Between Any Value and ERRP — Indicates a brief power failure has occurred. In this condition the Rampmaster continues to run the
program.
Display Reading PF—Indicates an extended power failure has occurred. In this condition the Rampmaster stops running the program.
Rampmaster Display Messages
Add TEMP Add Temperature, page 11 FACT Factory, page 17 PF Power Failure, page 10
Add TIME Add Time, page 11 FAIL Fail, page 21 RA x Rate, page 6
ALRM Alarm, page 12 FAST Fast, N/A RALL Restore All, N/A
bd T Board Temperature, page 19 FLLd Full Load Voltage, page 19 ROR Rate of Rise, page 19
°C x
Temperature, page 6
FUSE
Fuse, N/A
RSTR
Restore, N/A
CANL
Cancel, page 12
Hd x
Hold, page 6
SEGS
Segments, page 6
CAST Cast, N/A Id Identification, page 18 SETP Set point, page 11
CHG° Change°, page 18 LAM Laminate, N/A SKIP TO SEG Skip to Segment, page 11
Co82 COE 82, N/A LEdS LED’s, page 19 SLOW Slow, N/A
Co90
COE 90, N/A
MAX
Maximum, page 18
SOFT
Soften, N/A
Co96 COE 96, N/A MEd Medium, N/A STbY Standby, pages 9
CPL Complete, page 6 MIN Minimum, page 18 STOP Stop, pages 7
CPLT Process Complete, page 7 MODX Modify Express Mode, N/A SUSP Suspend, page 12
dELA
Delay Start, page 17
N-A
Not Available
SW V
Software Version, page 19
dIAG
Diagnostics, page 17
NOLd
No Load Voltage, page 19
SYST
System, page 17
EdIT Edit, N/A OFF Off, pages 18 TEMP Temperature, page 17
ERCd Error Codes, page 18 ON On, pages 18 TIME Time, page 17
Err ERTF Related, page 19 -ON- On, pages 7 VIEW View, page 18
ErrP
Brief Power Failure, page 10
OPT
Options, page 17
VOLT
Voltage, page 19
Errx Error Code, page 21 OUTS Outputs, page 19 WAIT Wait, page 13
ERTF
Error Temp. & Time of Error,
page 19
OUT1, OUT2,
OUT3, OUT4
Outputs, page 19 XSLO Extra Slow, N/A
°F x
Temperature, page 6
PCT
Percent, N/A
2KEY
Two Key, page 18
