Pre-installation (continued)
Attaching the pool cover
base to the pump
□ Line up the pump (A) on the pool cover base (B).
□ There are three (3) feet on the bottom of the
pump (A) that must sit in the holes of the pool
cover base (B).
□ Once the pump (A) is in place, hold the pump (A)
and pool cover base (B) together, and turn over.
□ Using the three included Phillip head screws (D),
attach the pool cover base (B) to the pump (A).
NOTE: Periodically remove this base to clear any
debris that may collect in the base. A clear path for
the water will allow the pump to perform its best.
□ Attach the garden hose adapter (C) to the pump
(A) discharge.
NOTE: For greater flow rate, use a 1-1/4 in. flexible
discharge hose, and keep hose lengths as short as
possible (50 ft. or less). Narrow and long discharge
hoses restrict the flow.
A 1-1/4 in. female threaded coupler may need to be
purchased separately for connection with the
flexible discharge hose.
Individual branch circuit required
1-1/4 in. Male NPT or 3/4 in. garden
hose connection
1-1/4 in. Flexible Discharge Hose or 3/4
in. garden hose
