Care and Cleaning
Do
□ When the power is disconnected, inspect the pool
cover base and the pump intake screen (bottom of
pump) and remove all debris, then plug the pump
back into the grounded outlet.
Do Not
□ Do not disassemble the motor housing. This motor
has NO repairable internal parts, and disassembly
may cause leakage or dangerous electrical wiring
issues.
□ Do not lift the pump by the power cord.
To clean a pump clogged with debris:
□ Unplug the pump from electrical power.
□ Remove the screws and pool cover base from the pump.
□ Remove the screws and screen from the bottom of the pump.
□ Remove the screws, volute, and seal gasket from the pump.
□ Clean the debris from the impeller and pool cover base. Reassemble.
□ If debris is preventing the float switch from operating properly, remove any debris from the float switch cage on the
side of the pump. The bottom portion of this cage can be removed for further cleaning.
□ Contact the Customer Service Team at 1-844-251-7446 or visit HOMEDEPOT.COM for any replacement parts.
Item
Description
Qty
1
3/4 in. Garden hose adapter
1
2
Pump casing and motor
1
3
Float switch
1
4
Impeller
1
5
Seal gasket
1
6
Washer
1
7
Nut
1
8
Volute
1
9
Volute screws
8
10
Screen
1
11
Screen screws
3
12
Pool cover base
1
13
Pool cover base screws
3
2
4
5
6
8
3
9
10
11
7
13
12
1
