LOCATED IN THE FRAME. SEE DIAGRAMS ABOVE FOR DETAILS.
5. REPEAT ALL OF THE ABOVE FOR THE REMAINING 3 CASTORS.
4. ATTACH THE CASTOR TO THE FRAME USING 3 x M5 SCREWS (PART 14) UNTIL FULLY TIGHTENED.
3. ALIGN HOLES IN THE CASTOR PLATE TO THE CORRESPONDING HOLES OF THE NUTSERTS WHICH ARE
2. PLACE A CASTOR (PART 27) ONTO THE BASE FRAME AS SHOWN.
1. PLACE TROLLEY BASE (PART 2) UPSIDE DOWN, AS SHOWN IN THE DIAGRAM ABOVE.
FITTING OF THE CASTORS TO THE BASE ASSEMBLY
VIEW OF NUTSERTS
A
FITTED CASTOR
FINAL VIEW OF
2
14
FRONT
14
14
27
FLINDERS, NORFOLK, DAINTREE & KIMBERLEY TROLLEY ASSEMBLY
14
