STYLE, GRILLED TO PERFECTION
6. REPEAT ALL OF THE ABOVE STEPS FOR THE OTHER TROLLEY SIDE PANEL.
5. ATTACH 1 x 5mm DIAMETER WASHER (PART 23) & 1 x M5 NUT (PART 18) TO THE SCREW AND
THROUGH THE HOLE OF THE 'L' BRACKET (PART 26).
4. PLACE 1 x M5 SCREW (PART 14) THROUGH THE HOLE OF THE TROLLEY SIDE PANEL AND
3. ATTACH 1 x 5mm DIAMETER WASHER (PART 23) & 1 x M5 NUT (PART 18) TO THE SCREW AND
THROUGH THE HOLE OF THE TROLLEY BASE PANEL.
2. PLACE 1 x M5 SCREW (PART 14) THROUGH THE HOLE OF THE 'L' BRACKET (PART 26) AND
1. ALIGN THE HOLES IN THE 'L' BRACKET (PART 26) WITH THE HOLES IN THE TROLLEY BASE.
FITTING OF THE 'L' BRACKETS
KIMBERLEY TROLLEY ASSEMBLY
FULLY TIGHTEN.
FULLY TIGHTEN.
G
OF THE 'L' BRACKETS AND FASTENERS
ENLARGED VIEW TO SHOW FINAL ATTACHMENT
18
23
14
18
23
14
26
20
