4. FOR FLINDERS, NORFOLK & DAINTREE BARBECUES SEE PAGE 22 FOR NEXT INSTRUCTION.
3. FULLY TIGHTEN THE SCREWS. REPEAT FOR THE REMAINING 3 CATCHES.
2. ATTACH THE CATCH BY USING 2 x ST3.5x10 SCREWS (PART 16) AND A PHILLIPS HEAD SCREW DRIVER.
1. PLACE 1 x MAGNETIC CATCH (PART 25) INTO POSITION AS SHOWN ABOVE.
FITTING OF THE MAGNETIC CATCHES TO THE CABINET
FLINDERS, NORFOLK, DAINTREE & KIMBERLEY TROLLEY ASSEMBLY
F
FOR FITTING THE MAGNETIC CATCHES
ENLARGED VIEW OF HOLES
16
16
16
25
25
16
19
