Everdure FLINDERS - Page 18

STYLE, GRILLED TO PERFECTION
4. REPEAT THE ABOVE STEPS FOR THE OTHER POSITIONS AS SHOWN ABOVE.
3. PLACE 1 x 5mm DIAMETER WASHER (PART 23) AND 1 x M5 NUT (PART 18) ONTO THE M5 SCREW AND
CORRESPONDING HOLE OF THE TROLLEY SIDE PANEL (PART 3 OR 4).
2. PLACE 1 X M5 SCREW (PART 14) THROUGH A HOLE IN ONE OF THE INFILL PANELS AND THROUGH THE
1. GENTLY LOWER THE BARBECUE ASSEMBLY ONTO THE BASE AS SHOWN ABOVE.
ATTACHING THE BARBECUE TO THE BASE ASSEMBLY
FLINDERS, NORFOLK, DAINTREE & KIMBERLEY TROLLEY ASSEMBLY
FULLY TIGHTEN.
E
FROM THE FRONT. SEE DIAGRAM.
WHEN LOOKING AT THE BARBECUE
BASE IS TO THE LEFT HAND SIDE,
THAT THE LARGE HOLE IN THE
NOTE: FOR PROPANE BARBECUES, ENSURE
AND BOTTOM DOOR INFILL PANEL
ATTACHMENT OF TROLLEY SIDE
ENLARGED VIEW FOR
14
14
14
18
23
23
18
14
23
23
18
18
18
