NOTE: DO NOT FULLY TIGHTEN THESE SCREWS AT THIS STAGE.
6. REPEAT STEPS 3 TO 5 FOR THE REMAINING 3 POSITIONS.
5. ATTACH 1 x 5mm DIAMETER WASHER (PART 23) & 1 x M5 NUT (PART 18) ONTO THE SCREW.
CORRESPONDING HOLE OF THE TROLLEY SIDE PANEL.
4. PLACE 1 x M5 SCREW (PART 14) THROUGH THE HOLE OF THE INFILL PANEL AND THROUGH THE
3. ALIGN THE HOLES OF THE INFILL PANEL WITH THE HOLES IN THE TROLLEY SIDES.
2. PLACE THE INFILL PANEL INTO THE POSITION SHOWN IN THE ABOVE DIAGRAM.
IS UPSIDE DOWN.
1. THE TOP DOOR INFILL PANEL (PART 7) CAN BE ATTACHED TO THE TROLLEY SIDES, WHILE THE BARBECUE
ATTACHING TOP DOOR INFILL PANEL
FLINDERS, NORFOLK, DAINTREE & KIMBERLEY TROLLEY ASSEMBLY
D
14
7
14
23
23
18
18
17
