Assembly, Operation & Maintenance Instructions
PART NAME QTY
1 Pedestal Top 1
2 Pedestal Pole 1
3 Pole Support Cover 1
4 Pole Support 1
5 Pedestal Base Cover 1
6 Pedestal Base 1
7 M3 x 0.4in (10mm) Screw 6
8 Rubber Foot 6
9 M8 x 1in (25mm) Bolt 10
10 M4 x 0.3in (8mm) Screw 4
11 Pedestal Support Bracket 1
