Electrical System
Notice:
The bilge pump will start automatically when
there is sucient water in the bilge to activate
the oat switch. The oat switch is protected
by a circuit breaker located in the battery
switch panel and is always supplied current
when the batteries are connected.
Nav/Anc Lights
Press once to activate the navigation lights. Press
twice to activate the anchor lights only. Press a third
time to turn all lights o.
Courtesy Lights RGBW
An ON/O switch that controls the courtesy lights in
the deck areas.
Baitwell
Activates the centrifugal pump that supplies water
to the baitwell and the baitwell light.
Fresh Water
Activates the fresh water pump that supplies the
optional fresh water washdown in the cockpit. The
pump is the pressure demand type. The pressure
switch automatically controls the water pump when
the system is activated and properly primed.
Raw Water
Activates the raw water pump that supplies raw
water (seawater) to the raw water washdown hose
connection in the cockpit. The pump is the pressure
demand type. The pressure switch automatically con-
trols the water pump when the system is activated
and properly primed.
Fwd Fishbox
Activates the centrifugal pump that drains the sh-
box.
Power Ports
Activates the power ports located below the port and
starboard gunnels in the cockpit.
12 volt Receptacles
Provides electrical current for portable 12 volt equip-
ment. There are three 12 volt receptacles, two in
the helm switch panel and one in the console storage
compartment.
Helm Courtesy Lights
Activates the red LED lights above the helm.
Notice:
Red lights have less eect on night vision and
should be selected if you need to illuminate the
helm area while navigating at night.
Flood Lights
Activates the forward and rear ood (spreader) lights
located on the hardtop that illuminate the cockpit of
the boat.
Acc
Reserved for additional 12 volt equipment.
Additional DC Switch Panels
Trim Tab Switch
Located in the helm. This switch panel controls the
trim tab planes located on the transom of the boat.
It is protected by a circuit breaker located near the
switch. Please refer to the Helm Control Systems
chapter for detailed information on the operation of
the trim tab controls.
Jack Plate Switch (Optional)
Located in helm near the engine control. This switch
may be installed in the engine control handle or on
the helm console, depending on the installation in
your boat. It is typically a push button style switch
panel with separate UP and DOWN buttons that con-
trol the height of the engine on the transom. Please
refer to the Helm Control Systems chapter and the
jack plate owner’s manual for information regarding
the proper use of the jack plate installed on your boat.
Power Pole Switch (Optional)
Located in the helm. Controls the power pole
mounted on the transom.
Engine Trim and Tilt Switch
This switch is typically installed in the engine control
handle. It controls the trimming and tilting of the
engine. Please refer to the Helm Control Systems
chapter and the engine owner’s manual for infor-
mation regarding the proper use of the tilt and trim
switch.
6.5 36 volt Trolling Motor System
If your boat is equipped with the optional trolling
motor, it will also be equipped with a 36 volt DC
electrical system that provides power to the trolling
motor. The 36 volt system consists of three 12 volt,
deep cycle batteries wired in series, a three bank
DC battery charger and circuit protection. A heavy
duty outlet plug with a protective cover is installed
near the bow that provides the connection for the
trolling motor. The system is completely isolated
