83
Exterior Equipment
Forward Console Cooler/Seat
There is a removable cooler with a seat cushion
just forward of the console. It is secured to the
cockpit sole by special brackets and stretch cords.
The removable seat cushion is secured to the
cooler lid with snaps and a bolster on the hardtop
frame just above the cooler provides a backrest for
the cooler seat. The cooler drains to the cockpit
and should be cleaned thoroughly after each use.
THE COOLER COULD SLIDE UNEXPECTEDLY WHILE
UNDERWAY CAUSING DAMAGE TO THE BOAT OR INJURY TO
A PASSENGER SITTING ON THE COOLER SEAT IF IT IS NOT
SECURED PROPERLY. ALWAYS MAKE SURE THE COOLER IS
SECURED PROPERLY IN THE BRACKETS WITH THE STRAPS
BEFORE OPERATING THE BOAT.
11.5 243 Center Console
Leaning Post and Console
Aluminum Leaning Post
The leaning post/seat is made of welded powder
coated aluminum. The base accommodates a
large cooler that is secured with special brackets
and straps. Grab rails on the rear provide a hand-
hold for passengers.
The helm and passenger seat is equipped with
a ip up bolster to provide more room between
the seat and the helm. The bolster converts the
seat to a leaning post style seat with a backrest,
223 Center Console
Cooler Seat
243 Center Console
Bolster in Leaning Post Position
243 Center Console
Cooler Brackets and Hold Down Straps
allowing the operator and passenger to sit or
stand at the helm. A powder coated footrest
automatically folds out when the bolster is folded
to the seat position. Gas springs connected to the
linkage between the footrest and bolster secure
the bolster in the leaning post or seat positions.
To convert the seat to a leaning post, lift the front
of the seat cushion to raise the bolster and push
