Everlast EV1000 - Exploded Diagram Parts List

26
Exploded Diagram Parts List
Part Description Qty Part Description Qty
1 Front Base Frame 1 43 Cap (ø50.8) 8
2 Seat Support 1 44 Cap (ø60) 4
3 Rear Base Frame 1 45 Cap (ø25.4) 6
4 Seat Support Tube 1 46 Taper Cap 1
5 Upright Support Tube 1 47 Bushing 1
6 Leg Extension Tube 1 48 Selection Rod Bushing 1
7 Arm Curl Tube 1 49 Rubber Ring 2
8 Top Beam 1 50 Outer Side Cap 4
9 Press Bar 1 51 Pulley Hook 18
10 Buttery Arm-Left 1 52 Handle Grip 4
11 Buttery Arm-Right 1 53 Chain 2
12 Handle Bar 2 54 Knob (M12) 1
13 Lat Bar 1 55 Hook 5
14 Lower Bar 1 56 Pin (M10 x 80mm) 1
15 Foam Tube 2 57 Pin (M10 x 70mm) 1
16 Bracket for Backrest 2 58 Selection Pin 1
17 Single Pulley 2 59 Stepper Pin 1
18 Pulley U 1 60 Hex Bolt (M8 x 10mm) 8
19 Reverse U 1 61 Hex Bolt (M8 x 15mm) 10
20 Selection Rod 1 62 Hex Bolt (M5 x 20mm) 12
21 Weight Guide Rod 2 63 Hex Bolt (M10 x 40mm) 1
22 Pulley Bracket 1 64 Hex Bolt (M10 x 45mm) 10
23 Stepper 1 65 Hex Bolt (M10 x 60mm) 2
24 Shroud Bracket 4 66 Hex Bolt (M10 x 70mm) 1
25 Shroud 2 67 Hex Bolt (M10 x 75mm) 1
26 Top Weight Plate 1 68 Carriage Bolt (M10 x 70mm) 2
27 Weight Plate 14 69 Hex Bolt (M10 x 80mm) 10
28 Upper Cable (ø7 x 3000 mm) 1 70 Hex Bolt (M12 x 75mm) 1
29 Buttery Cable (ø7 x 2535 mm) 1 71 Hex Bolt (M12 x 80mm) 2
30 Lower Cable (ø7 x 3450 mm) 1 72 Axle 1
31 Arm Curl Cushion 1 73 Oil Bushing (Big ø16) 2
32 Seat Cushion 1 74 Oil Bushing (ø12) 4
33 Backrest Cushion 1 75 Arc Washer (M8) 10
34 Big Foam 2 76 Arc Washer (ø22 x ø10.5 x 1 mm) 4
35 Foam 4 77 Washer (ø24 x ø12.5 x 1.5 mm) 8
36 Hand Foam 2 78 Washer (ø16 x ø8.5 x 1 mm) 22
37 Pulley (ø90 x 20 mm) 2 79 Washer (ø20 x ø10.5 x 1.2 mm) 50
38 Pulley (ø100 x 20 mm) 1 80 Selection Rod Washer 1
39 Pulley (ø90 x 26 mm) 10 81 Selection Rod Pin 1
40 Plastic Bushing (Small) 2 82 Nylon Nut (M8) 2
41 Plastic Bushing 2 83 Nylon Nut (M10) 29
42 Rubber 2 84 Nylon Nut (M12) 5
