Ruler - Use this ruler to help correctly identify the hardware
Note: Cut out this page to help fixing identification during assembly.
4
Components - Fixings
Note: Some of the smaller components may be pre-fitted to larger components. Please check carefully
before contacting Argos regarding any missing components.
Please check you have all the fixings listed below
32
Seat Cushion x 1
33
Backrest Cushion x 1
34
Big Foam x 2
35
Foam x 4
36
Handle Foam x 2
37
Pulley (Small) x 2
38
Pulley (Big) x 1
39
Pulley x 10
40
Plastic Bushing (Small) x 2
41
Plastic Bushing x 2
42
Rubber x 2
43
ø50.8 Cap x 8
44
ø60 Cap x 4
45
ø25.4 Cap x 6
46
Taper Cap x 1
47
Bushing x 1
48
Bushing x 1
49
Rubber Ring x 2
50
Out Side Cap x 4
51
Pulley Hook x 18
52
Handle Grip x 4
53
Chain x 2
54
Knob x 1
55
Hook x 5
56
M10x80mm Pin x 1
57
M10x70mm Pin x 1
58
Selection Pin x 1
59
Stepper Pin x 1
60
M8x10mm Hex Bolt x 8
61
M8x15mm Hex Bolt x 10
62
M8x20mm Hex Bolt x 12
63
M10x40mm Hex Bolt x 1
64
M10x45mm Hex Bolt x 10
65
M10x60mm Hex Bolt x 2
66
M10x70mm Hex Bolt x 1
67
M10x75mm Hex Bolt x 1
68
M10x70mm Carriage Bolt x 2
69
M10x80mm Hex Bolt x 10
70
M12x75mm Hex Bolt x 1
71
M12x80mm Hex Bolt x 2
72
Axle x 1
73
ø16 Oil Bushing (Big) x 2
74
ø12 Oil Bushing x 4
75
M8 Arc Washer x 10
76
M10 Arc Washer x 4
77
M12 Washer x 8
78
M8 Washer x 22
79
M10 Washer x 50
80
Selection Rod Washer x 1
81
Selection Rod Pin x 1
82
M8 Nylon Nut x 2
83
M10 Nylon Nut x 29
84
M12 Nylon Nut x 5
To Next Page
