2.7 DHW capacity
The table below shows the DHW capacity according to the primary flow rate and the PHE
model.
Model Primary Primary Primary In/Out DHW
EVINOX PART NR. Plates l/h Supply °C Return °C °C l/h
MTP30‐6/18
207/30 800 80 45 10/50 690
MTP30‐6/18
207/30 1000 80 45 10/50 840
MTP30‐6/18
207/30 1200 80 45 10/50 950
MTP30‐6/18
207/30 800 70 45 10/50 490
MTP30‐6/18
207/30 1000 70 45 10/50 600
MTP30‐6/18
207/30 1200 70 45 10/50 720
MTP44‐6/18
207/40 1000 80 45 10/50 860
MTP44‐6/18
207/40 1200 80 45 10/50 1000
MTP44‐6/18
207/40 1400 80 45 10/50 1200
MTP44‐6/18
207/40 1000 70 45 10/50 620
MTP44‐6/18
207/40 1200 70 45 10/50 740
MTP44‐6/18
207/40 1400 70 45 10/50 860
2.8 Heating capacity
The table here below shows the heating capacity according to the primary flow rate and
the PHE model.
Model Primary Primary Primary In/Out Power
EVINOX PART NR. Plates l/h Supply °C Return °C °C kW
MTP30/44‐6
207/10 800 80 70 50/70 9,1
MTP30/44‐6
207/10 1000 80 70 50/70 11,3
MTP30/44‐6
207/10 1200 80 70 50/70 13,6
MTP30/44‐6
207/10 800 70 60 40/50 9,1
MTP30/44‐6
207/10 1000 70 60 40/50 11,3
MTP30/44‐6
207/10 1200 70 60 40/50 13,6
MTP30/44‐18
207/20 800 80 60 40/70 18,2
MTP30/44‐18
207/20 1000 80 60 40/70 22,7
MTP30/44‐18
207/20 1200 80 60 40/70 27,3
MTP30/44‐18
207/20 800 70 55 40/55 13,7
MTP30/44‐18
207/20 1000 70 55 40/55 17,1
MTP30/44‐18
207/20 1200 70 55 40/55 20,5
It is recommended to feed the ModuSat TP with no less than 800 l/h.
