23
3 INSTALLATION
All ModuSat TP’s are delivered in protective packaging, after removing it check the
integrity of the unit as well as the presence of all parts. In case of damage or missing parts
contact Evinox.
Packaging materials must not be left at children’s reach because they are potentially
harmful.
The installation and commissioning must be carried out only by authorised and qualified
personnel according to the local governing laws and regulations.
Before connecting the ModuSat TP to the piping, wash the piping
thoroughly and remove all residual parts of metal and any other dirt that
may be present and would compromise the correct operation.
Next rinse the entire circuit to make sure all products used to wash it are
removed. During this process, it’s forbidden to use any chemical or other products
not approved by EVINOX. The non observance of this rule invalidated the warranty.
Make sure the environment where the ModuSat TP is to be installed complies with
governing rules and laws.
There is no limitation about where the unit can be located due to size and air flow.
In order not to compromise the correct unit operation the site working temperature must be
within the limits indicated in the product technical specifications and the unit must be
sheltered from atmospheric agents (harsh weather).
Remove the electric power supply before any installation operation.
The unit needs a 230/240Vac – 50Hz supply line, check also the Line and Phase polarity.
Protect the cables so to prevent any damage.
Make sure an efficient earth connection is present to guarantee the safety against electric
shocks.
Have the electric wiring checked by qualified personnel; EVINOX will not be liable for
damage caused by incorrect electric wiring, bad or missing earth connection.
Check also that the electric supply line is protected by a thermal and a differential switch.
These switches must be adequate for the ModuSat TP current consumption and the wiring
cables must be adequately sized.
It is ABSOLUTELY FORBIDDEN to use the piping’s for electric earth connections.
ModuSat TP has no protection against lightning or other overvoltage shocks.
In case an antifreeze fluid is required, ONLY EVINOX APPROVED products are
allowed. The non observance of this directive may result in the damage of the units
and circuits.
Don’t install or stock this product outdoor. ModuSat TP is designed to be used
only inside and in a protected area.
In order not to compromise the correct unit operation the site working
temperature must be within the limits indicated in the product technical specifications.
Repair work must be carried out using original spare parts only and must be done
by qualified personnel only. The non observance of this directive may
compromise the unit operation and performance. This will decline any
responsibility from the manufacturer and supplier.
