Product Information
SPECIFICATIONS
25, 30 Models
Displacement 35.1 cu. in. (576 cc)
Engine Type In-line, 2 Cylinder, Two-Cycle, E-TEC
Full Throttle Operating
Range
25 HP – 5000 to 6000 RPM
30 HP – 5000 to 6000 RPM
Power
(1)
(1) Rated following the standards of ICOMIA 28.83, ISO 3046 and NMMA.
25 HP – 25 HP (18.4 kw) @ 5500 RPM
30 HP – 30 HP (22.1 kw) @ 5500 RPM
Idle RPM in Neutral
(2)
(2) Emission Control Information.
700 ± 50
Ignition Timing
(2)
Not Adjustable
Emission Control System:
per SAE J1930
(2)
ECM, E-TEC (Engine Control Module, E-TEC)
Fuel Requirements
(2)
87 Pump Posted AKI (90 RON)
– Refer to Fuel Requirements on page 18
Oil – Lubricant
– Capacity
TC-W3 NMMA-certified oil or Evinrude/Johnson XD100 oil
– Refer to Oil Requirements on page 16
1.5 qt. (1.4 l)
Warning Signals Controlled by the outboard’s EMM
Battery, Minimum
(3)
(3) Use a 800 CCA (1000 MCA) battery when operating in temperatures below 32°F (0°C).
640 CCA (800 MCA) 12 volt or
800 CCA (1000 MCA) 12 volt below 32°F (0°C)
Spark Plug
(2)
Refer to ECI Label
Fuses Refer to Fuse on page 48
Fuel Filter In-line Replaceable
Battery Charging 15-Amp, Fully Regulated
Gearcase – Lubricant
(4)
– Capacity
(4) Use Evinrude/Johnson HPF Pro Gearcase Lubricant for high performance outboards and commercial
applications. Evinrude/Johnson HPF Pro Gearcase Lubricant delivers exceptional durability and reliability
and promotes long gearcase life in marine use.
Evinrude HPF XR
11 fl. oz. (325 ml)
Power Trim/Tilt – Fluid
Capacity
11.7 fl. oz. (345 ml)
Propeller Refer to Propeller Selection on page 61
Weight DR / RL Models 142 /148 lbs. (64 / 67 Kg)
DTE / DTEL Models 148 / 154 lbs. (67 / 70 Kg)
EL / PL Models 169 / 178 lbs. (77 / 81 Kg)
Sound at Drivers Ear
(LpA) ICOMIA 39.94
76.8 dB(A)
Transom Height R / TE Models 14 1/2 to 15 in (368 to 381 mm)
RL / TEL / DPL Models 19 1/2 to 20 in (495 to 508 mm)
