210mm (8-1/4”) TCT MULTIPURPOSE SLIDING MITRE SAWS
Specification Metric Imperial
Designed to cut
Mild Steel Plate – Max Thickness 3mm 1/8”
Mild Steel Box Section – Max Wall Thickness 3mm 1/8”
Wood – Max Section 60mm x 220mm 2-3/8” x 8-3/4”
Motor (230-240V~ 50Hz) 1500W 7A
No Load Speed 3750min
-1
3750rpm
Blade Dimensions
Diameter 210mm 8-1/4”
Bore Diameter 25.4mm 1”
Number of Teeth 20 20
Max Speed 5000min
-1
5000rpm
Thickness 1.7mm 2/8”
Weight N: 13kg / G: 14.6kg N: 29lb / G: 32lb
Laser
Laser Class Class 2
Laser Source Laser Diode
Laser Power 1 Max mW
Wave Length 650nm
Noise & Vibration Data
Sound Pressure Level L
PA
: 94.54 dB(A) K
PA
= 3 dB(A)
Sound Power Level L
WA
: 107.54 dB(A) K
WA
= 3 dB(A)
Vibration Level 2.561 m/s
2
K = 1.5m/s
2
Mitre Bevel Max Width Of Cut Max Depth Of Cut
0° 0° 220mm (8-3/4”) 60mm (2-3/8”)
45L° / 45R° 45° 140mm (5-1/2”) 35mm (1-3/8”)
45L° / 45R° 0° 140mm (5-1/2”) 60mm (2-3/8”)
0° 45° 220mm (8-3/4”) 35mm (1-3/8”)
6
www.evolutionpowertools.com
