SPECIFICATIONS R230DCT R255DCT R300DCT R12DCT R14DCT
Product Code
USA
009-0004 009-0004X 010-0004 010-0004X 012-0004 012-0004X 012-0004A 012-0004AX 130-0004 130-0004X
Motor USA
(120V~ 60Hz)
15A 15A 15A 15A 20A
Rated Speed
(min
-1
)
6000 6000 4600 4600 3750
Recommended
Max duty cycle
20 mins
Net Weight (lbs)
15.7lbs 16.1lbs 21.4lbs 21.4lbs 31.3 Lbs
Cable Length
3m (10ft) 4m (13ft) 3m (10ft) 4m (13ft) 4m (13f t)
Spindle Thread
Size
M8
Cutting Capacity
At 90°
90mm (3-1/12”) 102.5mm (4-1/16”) 115mm (4 -1/2” ) 115mm (4 -1/2” ) 130mm (5-1/8")
Blade Supplied
General
Diamond
No Blade
Included
General
Diamond
No Blade
Included
Premium
Diamond
No Blade
Included
Premium
Diamond
No Blade
Included
Premium
Diamond
No Blade
Included
Diameter
230mm (9”) 255mm (10”) 300mm (12” ) 30 0mm (12”) 350mm (14")
USA Bore
7/8” 7/8” 1” 1” 1"
NOISE & VIBRATION
DATA
Sound Pressure
Max L
p
a
98.0dB(A) K=3dB(A)
Sound Power
Level Max
L
w
a
109.0dB(A) K=3dB(A)
Handle Vibration
Max Level
6.15m/s
2
K=1.5m/s
2
power tools that have the switch on invites accidents.
• Remove any adjusting key or wrench before turning the
power tool on. A wrench or key left attached to a rotating
part of a power tool may result in personal injury.
• Do not overreach. Keep proper footing and balance at
all times. This enables better control of the power tool in
unexpected situations.
• Dress properly. Do not wear loose clothing or jewellery.
Keep your hair and clothing away from moving parts.
Loose clothes, jewellery or long hair can be caught in
moving parts.
• If devices are provided for the connection of dust
extraction and collection facilities, ensure that these are
connected and properly used. Use of dust collection can
reduce dust-related hazards.
• Do not let familiarity gained from frequent use of tools
allow you to become complacent and ignore tool safety
principles. A careless action can cause severe injury within
a fraction of a second.
POWER TOOL USE AND CARE
• Do not force the power tool. Use the correct power tool
for your application. The correct power tool will do the job
better and safer at a rate for which it was designed.
• Do not use the power tool if the switch does not turn it
on and off. Any power tool that cannot be controlled with
the switch is dangerous and must be repaired.
• Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from the
power tool before making any adjustments, changing
accessories, or storing power tools. Such preventive
safety measures reduce the risk of starting the power tool
accidentally.
• Store idle power tools out of the reach of children and
do not allow persons unfamiliar with the power tool or
these instructions to operate the power tool. Power tools
are dangerous in the hands of untrained users.
• Maintain power tools and accessories. Check for
misalignment or binding of moving parts, breakage
of parts and any other condition that may affect the
power tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused by poorly
maintained power tools.
• Keep cutting tools sharp and clean. Properly maintained
cutting tools with sharp cutting edges are less likely to bind
and are easier to control.
• Use the power tool, accessories and tool bits etc. in
accordance with these instructions, taking into account
the working conditions and the work to be performed.
Use of the power tool for operations different from those
intended could result in a hazardous situation.
• Keep handles and grasping surfaces dry, clean and
free from oil and grease. Slippery handles and grasping
surfaces do not allow for safe handling and control of the
tool in unexpected situations.
POWER TOOL SERVICE
• Have your power tool serviced by a qualified repair
person using only identical replacement parts. This will
ensure that the safety of the power tool is maintained.
SAFETY INSTRUCTIONS FOR CUT OFF SAWS
• The guard provided with the tool must be securely
attached to the power tool and positioned for maximum
safety, so the least amount of wheel is exposed towards
the operator. Position yourself and bystanders away
from the plane of the rotating wheel. The guard helps
to protect operator from broken wheel fragments and
accidental contact with wheel.
• Use only diamond cut-off wheels for your power tool.
Just because an accessory can be attached to your power
tool, it does not assure safe operation.
• The rated speed of the accessory must be at least equal
to the maximum speed marked on the power tool.
Accessories running faster than their rated speed can break
and fly apart.
• Wheels must be used only for recommended
applications. For example: do not grind with the side
of cut-off wheel. Abrasive cut-off wheels are intended for
peripheral grinding, side forces applied to these wheels may
cause them to shatter.
• Always use undamaged wheel flanges that are of correct
diameter for your selected wheel. Proper wheel flanges
support the wheel thus reducing the possibility of wheel
breakage.
• The outside diameter and the thickness of your
accessory must be within the capacity rating of your
power tool. Incorrectly sized accessories cannot be
adequately guarded or controlled.
• The arbour size of wheels and flanges must properly fit
the spindle of the power tool. Wheels and flanges with
arbour holes that do not match the mounting hardware of
the power tool will run out of balance, vibrate excessively
and may cause loss of control.
• Do not use damaged wheels. Before each use, inspect
the wheels for chips and cracks. If power tool or wheel is
dropped, inspect for damage or install an undamaged
wheel. After inspecting and installing the wheel,
position yourself and bystanders away from the plane of
the rotating wheel and run the power tool at maximum
no load speed for one minute. Damaged wheels will
normally break apart during this test time.
• Wear personal protective equipment. Depending
on application, use face shield, safety goggles or
safety glasses. As appropriate, wear dust mask,
hearing protectors, gloves and shop apron capable
of stopping small abrasive or workpiece fragments.
The eye protection must be capable of stopping flying
debris generated by various operations. The dust mask or
respirator must be capable of filtrating particles generated
by your operation. Prolonged exposure to high intensity
noise may cause hearing loss.
• Keep bystanders a safe distance away from work area.
Anyone entering the work area must wear personal
protective equipment. Fragments of workpiece or of
a broken wheel may fly away and cause injury beyond
immediate area of operation.
• Hold the power tool by insulated gripping surfaces
only, when performing an operation where the cutting
accessory may contact hidden wiring or its own cord.
Cutting accessory contacting a “live” wire may make
exposed metal parts of the power tool “live” and could give
the operator an electric shock.
• Position the cord clear of the spinning accessory. If you
lose control, the cord may be cut or snagged and your hand
or arm may be pulled into the spinning wheel.
• Never lay the power tool down until the accessory has
come to a complete stop. The spinning wheel may grab
the surface and pull the power tool out of your control.
• Do not run the power tool while carrying it at your side.
Accidental contact with the spinning accessory could snag
your clothing, pulling the accessory into your body.
• Regularly clean the power tool’s air vents. The motor’s
fan will draw the dust inside the housing and excessive
accumulation of powdered metal may cause electrical
hazards.
• Do not operate the power tool near flammable
materials. Sparks could ignite these materials.
FURTHER SAFETY INSTRUCTIONS FOR ABRASIVE
CUTTING-OFF OPERATION
Kickback and related warnings
Kickback is a sudden reaction to a pinched or snagged
rotating wheel. Pinching or snagging causes rapid stalling
of the rotating wheel which in turn causes the uncontrolled
