24
www.evolutionpowertools.com
BEVEL RIPPING
Bevel ripping is cutting along the length of a work-piece with
the saw blade tilted at an angle.
When performing a bevel cut, ensure the rip fence is on the
right hand side of the blade. (Fig 42)
MAINTENANCE
WARNING: Ensure that the machine is disconnected from the
mains supply before any maintenance tasks or adjustments
are attempted.
CHANGING THE BLADE
Note: We recommend that the operator considers wearing
protective gloves when handling or changing the machines blade.
• Disconnect the machine from the power supply
• Remove the top blade guard. (refer to TOP BLADE GUARD
on page 17)
• Remove the table access plate by removing the countersunk
head screw from the front edge of the access plate. (Fig. 43)
• Lift the plate away and carefully store it and its xing screw
for future use.
• Raise the blade to its highest position.
• Use the two blade changing spanners provided. One spanner
will t the hexagonal nut machined onto the outer blade
ange, and thus prevent the arbor from rotating. The other
spanner will t the arbor nut. (Fig 44)
• Remove the arbor nut, the outer blade ange and the blade.
• Thoroughly clean any debris from these parts and also from
the exposed motor arbor and inner blade ange. The inner
blade ange can be left in situ.
• Fit the new blade. Ensure that the teeth are facing to the
front of the saw (Fig. 45), and that the rotation arrow on
the blade is in conformism with the rotation arrow on the
motor housing.
• Replace the outer ange and nut and tighten securely with
the spanners provided. Check that both blade anges are in
contact with the blade.
• Replace the table access plate and its xing screw.
Ensure that the xing screw is correctly seated.
• Replace the top blade guard.
REPLACING DAMAGED CABLE
If cable is damaged in any way, ensure it is repaired by
Evolution or one of its approved agents.
Fig. 42
Fig. 43
Fig. 44
Fig. 45
