3
www.evolutionpowertools.com
EN
MACHINE SPECIFICATIONS
MACHINE METRIC IMPERIAL
Motor (UK/EU) 220-240v ~ 50Hz 1300W (S1)
1500W (S6 40%)
5.65A
Maximum Table Surface Area 583 x 901mm 22-15/16” x 35-1/2”
Dimensions With Leg Assembly
(Height x Width x Length)
825 x 901 x 583mm 32-1/2” x 35-1/2” x 22-15/16”
Dimensions Without Leg Assembly
(Height x Width x Length)
300 x 901 x 583mm 12” x 35-1/2” x 22-15/16”
Riving Knife Thickness 1.8mm 5/64”
Speed No Load 3250min
-1
3250rpm
Net weight 20.14kg 44.4lbs
Gross weight 23kg 50.7lbs
CUTTING CAPACITY METRIC IMPERIAL
Max Depth of Cut at 90° (Excludes metal) 85mm 3-1/4”
Max Depth of Cut at 45° (Excludes metal) 65mm 2-1/2”
Max Metal Square Tube
(Height x Width x Thickness)
60 x 80 x 3mm 2-5/16” x 3-2/16” x 1/8”
Max Metal Round Tube (Diameter x Thickness) 76 x 3mm 2-15/16” x 1\8”
Max Plate Size
(Height x Width x Max Cutting Thickness)
1500 x 230 x 3mm 59-1/32” x 9-1/16” x 1/8”
Metal Hardness Max. 220HB
Rip Capacity - Right of the Blade 400mm 15-3/4”
Rip Capacity - Left of the Blade 495mm 19-1/2”
BLADE METRIC IMPERIAL
Diameter 255mm 10”
Bore 25.4mm 1”
Number of Teeth 24 24
Kerf 2mm 5/64”
NOISE & VIBRATION DATA
Sound Pressure LPA 94 dB(A)
Sound Power Level L
W
A 107dB(A)
Uncertainty K 3dB(A)
WARNING: If the workpiece becomes stuck during or
after cutting, turn off the machine and unplug from
the power supply. Carefully remove the workpiece
and check that the blade is able to spin freely.
You may need to move the fence or use the push
stick provided to remove the cut off piece. Restore
power to the machine and turn it on to check that it
is operating correctly before making another cut.
