Evolution R255 MTS User Manual

11
www.evolutionpowertools.com
EN
MACHINE OVERVIEW
10
14
15
3
2
8
7
13
16
17
12
6
5
9
11
G
F
1
4
1. ON/OFF SWITCH
2. RIVING KNIFE
3. BLADE GUARD
4. BLADE
5. BEVEL LOCKING KNOB
6. RISE AND FALL/BEVEL ADJUSTMENT
HAND WHEEL
7. RIP FENCE SCALE MAGNIFIER
8. RIP FENCE LOCKING HANDLE
9. PUSH STICK
10. RIP FENCE
11. REAR CANTILEVER BRACES
12. ANTI-BOUNCE DEVICE
13. SLIDING MITRE FENCE
14. DUST PORT
15. DUST HOSE
16. REAR DUST PORT
17. BLADE CHANGE SPANNERS

Evolution R255 MTS Specifications

General

Brand	Evolution
Model	R255 MTS
Category	Saw
Language	English
