Controls and Communications

This rear panel part presents some or all of the following connectors according to your

configuration:

• The Ref Video connectors allow the server to receive or send back the analog

genlock reference signal.

• The XNet2 connectors allow the interconnection of EVS servers, and/or XStore in an

XNet2 network. The IN connector of a server is connected to the OUT connector of

another server, and so on to form a closed loop network.

• The Multiviewer connectors allow a monitor to be connected directly to the server,

and to display PGM and REC channels as configured in the Multicam Configuration

window, in the Monitoring tab, Multiviewer page. See the Multicam Configuration

manual for a description of the configuration parameters.

• The Multiviewer connector provides an analog Multiviewer output on a DA-15

connectors, that can be configured in CVBS, RGB HD or YUV HD.

• The Loop connector allows the loop of PGM1 on REC1 to be able to use the internal

loop feature.

• The Timecode connectors allow the server to receive or send back the LTC timecode

reference signal.

• The Gigabit Ethernet connectors allow the interconnection of servers, other EVS,

and/or third-party systems into a Gigabit Ethernet network.

• The RS232 connector allows a tablet to be connected to the server.

• The GPI connector allows GPI (General Purpose Interface) devices to send or receive

electric pulses that will trigger commands on the server or to be connected with third-

party devices.

• The Console connector allows a monitor and a keyboard to be connected to the

server.

Controls and Communications

This rear panel part presents some or all of the following connectors according to your

configuration:

• The PC LAN connector allows connection of the PC LAN interface of the EVSserver

to an Ethernet network.

• The Audio Monitoring Output connector is a DA-15 connector that allows audio

output connections for monitoring purposes.

SAS-HDX

The SAS-HDX connector allows the connection to the external disk array SAS-HDX if it is

installed.
