EVS XT nano User Manual

Bandwidth and RT Channels at 150Hz (PAL SLSM 3x)
Codec
Field
Rate
(Hz)
Video
Bitrate
(Mbps)
Fields/
Block
Block-based
bandwidth
(MB/s)
Max. RT
Channels
Apple ProRes 422 LT 150.00 85 11 36.4 8.2
HD Mjpeg Standard 150.00 100 4 100.0 3.0
HD Mpeg-2 Intra 150.00 100 2 200.0 1.5
DVCPro HD 150.00 100 5 80.0 3.7
AVC Intra 100 150.00 111 4 100.0 3.0
Avid DNxHD® 120 150.00 120 9 44.5 6.7
Apple ProRes 422 150.00 120 7 57.2 5.2
Avid DNxHD® 185 150.00 185 5 80.0 3.7
Apple ProRes 422 HQ 150.00 185 5 80.0 3.7
Bandwidth and RT Channels at 59.94Hz (NTSC)
Codec
Field
Rate
(Hz)
Video
Bitrate
(Mbps)
Fields/
Block
Block-based
bandwidth
(MB/s)
Max. RT
Channels
Apple ProRes 422 LT 59.94 85 35 13.8 21.7
HD Mjpeg Standard 59.94 100 14 34.3 8.7
HD Mpeg-2 Intra 59.94 100 7 68.6 4.3
DVCPro HD 59.94 100 19 25.3 11.8
AVC Intra 100 59.94 111 17 28.3 10.6
Avid DNxHD® 145 59.94 145 27 17.8 16.8
Apple ProRes 422 59.94 145 24 20.0 15.0
Avid DNxHD® 220 59.94 220 18 26.7 11.2
Apple ProRes 422 HQ 59.94 220 16 30.0 10.0
16 4. Software Specifications
EVS Broadcast Equipment SA Issue 12.02.A- December 2013
