6.2.3. CODConnectivity in 3D Dual Link
Connector Assignments
This section describes the connector assignments and layout for the video standards HD
3D in Dual Link mode.
Connector 3D mode Connector label
J1 Not used CHAR SD
J2 SDI monitoring output (HD) Not wired to the backplane.
Used for onboard multiviewer input
J3 HD SDI program output for right
eye (3D)
(HD)
OUT B
J4 SDI monitoring output for left eye
(3D)
(HD/SD)
CHAR OUT SD/HD
J5 HD SDI input for right eye (3D)
(HD)
IN B
J6 HD SDI program output for left
eye (3D)
OUT
J7 Not used OUT
J8 HD SDI input for left eye (3D)
(HD)
IN
J9 Alternate HD SDI input
(HD, for the internal loop)
Not wired to the backplane.
J9 of REC1 only connected to Loop
connector.
Note
The loops of the input signal are not genlocked.
HARDWARE TECHNICAL REFERENCE MANUAL XTnano Server 12.02
6. Boards Description 49
