Backup Transfers
Internal 1GbE Connection
The maximum number of real-time transfers through 1GbE ports of the XTnano server in
1080i, are summarized in the following table:
Codec
Field
Rate
Video
Bitrate
(Mbps)
Block-
Based
Bandwidth
(MB/s)
RT
Transfers
Transfer
Speed
(faster than
RT)
Apple ProRes
422 LT
50.00 Hz 85 11.8 5.9 5.5x
HD Mjpeg
Standard
50.00 Hz 100 33.4 2.1 1.9x
HD Mpeg-2 Intra 50.00 Hz 100 66.7 1.0 0.9x
DVCPro HD 50.00 Hz 100 23.6 2.9 2.7x
AVC Intra 100 50.00 Hz 111 28.6 2.4 2.2x
Avid DNxHD®
120
50.00 Hz 120 14.9 4.7 4.3x
Apple ProRes
422
50.00 Hz 120 16.7 4.2 3.9x
Avid DNxHD®
185
50.00 Hz 185 22.3 3.1 2.9x
Apple ProRes
422 HQ
50.00 Hz 185 25.0 2.8 2.6x
