Specifications

• each pin can be individually configured as an output or an input

• internal 4K7 pull up to +5V

• low level Vi<1.5 Volt (U12=74HC245)

• high level Vi>3.5 Volt (U12=74HC245)

• optional TTL compatible level (U12=74HCT245)

HARDWARE TECHNICAL REFERENCE MANUAL XTnano Server 12.02

5. Hardware Installation and Cabling 41
