EVS XT nano User Manual

Base Board LEDs
The following table lists the LEDs available on the V3X base board with the genlock
functionality:
LED Color Status Function
GLK — Off The genlock module is not initialized.
Green Blinking The genlock module is properly initialized, but no valid
genlock signal is detected.
On The module is initialized and a valid genlock signal is
detected.
Red Blinking There is a genlock problem.
On A resync is needed.
PSU
OK
Green On All voltages are present and in the allowed range.
— Off There is a voltage problem.
V3X COD Modules LEDs
The following table lists the LEDs available on then V3X COD modules (from left to right):
LED Color Status Function
CPU Green Blinking Indicates CPU activity.
On There is a problem with the module processor.
PLAY Green On The module is set in play mode by the software.
Off The module is set in record mode.
PVID Green On A valid video signal has been detected on the J8
connector (SD/HD SDI input), whether the module is in
play or record mode.
TF
(transfer)
Green Blinking Data transfers occur between the module and the H3X
board.
M1 — — Not used.
M2
M3
M4
HARDWARE TECHNICAL REFERENCE MANUAL XTnano Server 12.02
6. Boards Description 45
