EVS XT nano User Manual

LEDs Function
The available LEDs on the XNet2CTL controller module are, from left to right:
LED Color Status Function
LED 1 Green On Ok.
Red On An error occurred while booting the H3X board.
LED 2 to
LED 8
— — For EVS internal use only.
FRAMER Green On Not used.
NET Green On Not used.
DSP Green Blinking Indicates DSP activity (audio processing).
The available LEDs on the GBE Gigabit module module are, from left to right:
LED Color Status Function
CPU1
CPU2
Green Blinking These LEDs blink alternately every 250 milliseconds to
indicate that the processor is running.
Other
LEDs
— — For EVS internal use only.
Gigabit Connectors
The two board Gigabit connectors are connected to the two backplane Gigabit ports.
The Gigabit connectors must be on a network that supports Jumbo Frames of (at least)
9014 bytes Ethernet frames. See section "Switches" on page 36 for the list of supported
switches.
You can set up the GbE IP addresses in the Multicam Configuration window, in the
Network tab, Gigabit Ethernet section.See the Configuration manual for more information.
54 6. Boards Description
EVS Broadcast Equipment SA Issue 12.02.A- December 2013
