In standard configuration the PC hardware is composed of:

• One mounting PC board, with serial ports, LTC reader and generator, is controlled by

the motherboard.

• IDE System Hard disk: the IDE disk drive is used for storing the EVS software and

the DOS operating system. Neither audio nor video data is saved on this disk. The

capacity of this drive may vary depending on market availability, but the system

partition is always set to 1GB. The remaining capacity of this drive is not used.

• 128MB SDRAM (or higher) modified. The SDRAM used has been modified to suit the

system requirements. Please contact EVS support for RAMs upgrade. Do not use

standard PC RAM modules.

Illustration

HARDWARE TECHNICAL REFERENCE MANUAL XTnano Server 12.02
