2.2 GPI IN CONNECTIONS
On XT2+ servers, GPI triggers are available. Refer to the Multicam or AirBox user
manuals for GPI allocation.
2.2.1 RELAY  OPTO INPUTS ON THE XT2+ SERVER (GPI INPUTS
1, 2, 3, 4)
2.2.2 RELAY  TTL INPUTS ON THE XT2+ SERVER (GPI INPUTS
5, 6, 7, 8)
The relay must be connected between the ground and the corresponding TTL input
on the DB25.
