CONNECTIVITY ON THE V3X COD A AND COD B MODULES
FOR
3D AND 1080P DUAL LINK
Connector Assignments
Connector 3D/1080p mode Connector label
J1 N/A CHAR SD
J2 SDI monitoring output
(SD, down-converted)
Not wired to the
backplane.
Used for onboard
multiviewer input
J3 HD SDI program output for right eye (3D) or link
2 (1080p)
(HD)
OUT B
J4 SDI monitoring output for left eye (3D) or link 1
(1080p)
(HD/SD)
CHAR OUT SD/HD
J5 HD SDI input for right eye (3D) or link 2 (1080p)
(HD)
IN B
J6 HD SDI program output for left eye (3D) or link 1
(1080p)
(HD)
OUT
J7 HD SDI program output for left eye (3D) or link 1
(1080p)
(HD, identical to J6)
OUT
J8 HD SDI input for left eye (3D) or link 1 (1080p)
(HD)
IN
J9 Alternate HD SDI input
(HD, for hardware loop)
Not wired to the
backplane.
Used for loop in.
Note
The loops of the input signal are not genlocked.
